JACK JK-A2C-C SINGLE NEEDLE POWER SAVING LOCKSTITCH FLATBED DD INDUSTRIAL SEWING MACHINE WITH COMPELETE SET

Name: JACK JK-A2C-C SINGLE NEEDLE POWER SAVING LOCKSTITCH FLATBED DD INDUSTRIAL SEWING MACHINE WITH COMPELETE SET
SKU: 5204
Availability: InStock

-3%

JACK JK-A2C-C SINGLE NEEDLE POWER SAVING LOCKSTITCH FLATBED DD INDUSTRIAL SEWING MACHINE WITH COMPELETE SET - Image 2

Original price was: ₹26,320.00.Current price is: ₹25,500.00.

Energy-saving direct-drive motor: The integrated servo motor provides significant power savings (up to 71% compared to conventional motors) and ensures a quieter, more stable operation.
Automatic thread trimming: Increases productivity and saves time by automatically cutting the thread after each seam. This feature is activated by using the foot pedal.
Automatic functions:
- Needle positioning: Automatically stops the needle in the correct position for seamless operation.
- Dormancy and safety switch: An automatic system that puts the machine into a low-power state when not in use.
High-torque motor: Offers a 15% increase in torque over traditional motors, enabling seamless stitching on thicker or more difficult fabrics within its material range.
Intuitive control panel: An easy-to-use smart panel allows operators to adjust settings like speed and needle position.
LED lighting: Built-in, three-level LED illumination reduces eye strain and provides clear visibility of the sewing area.
Centralized lubrication: A traditional oil pan ensures fully automatic lubrication for consistent performance.

Technical specifications

- Stitch type: Single-needle lockstitch.
- Fabric capability: Light to medium materials.
- Max sewing speed: Up to 5,000 stitches per minute (SPM).
- Max stitch length: 5 mm.

Presser foot lift height: 5 mm (manual) and up to 13 mm (knee lift).

Needle type: DBx1, with compatible sizes ranging from 11 to 18.

Thread count: 2.

Drive system: Integrated direct-drive servo motor.

Lubrication: Fully automatic.

Add to cart

Buy Now

Category: oile

The JACK JK-A2C-C is an industrial single-needle, lockstitch flatbed sewing machine designed for high performance, efficiency, and energy savings. It is specifically configured for sewing light to medium materials.
